SCAC

• Automatic Color Calibration: Real-time screen analysis with automatic black and white level adjustment
• Screen Calibration Tools: Provides black and white level calibration patterns for manual calibration
• UI Filtering: Intelligently excludes UI elements from luminance statistics
• History Smoothing: Multiple history smoothing algorithms to prevent flickering

• Custom Sampling Area: Supports full-screen or custom area sampling
• HDR/scRGB Support: Compatible with high dynamic range displays
• Debug View: Visualizes all reduction textures and historical data
• Real-time Statistics: Displays current frame's minimum/maximum luminance values

1. Ensure  ReShade  is installed
2. Copy the

   SCAC.fx

    file to ReShade's Shaders directory
3. Enable ReShade in-game and add the SCAC effect

1. Enable Auto Calibration: Turn on "Enable Auto calibration" in the "Auto calibration" category
2. Adjust Limiters:
   • Min White Limiter: Prevents overly bright dim scenes (recommended: 0.95)
   • Max Black Limiter: Avoids calibrating grey as black (recommended: 0.10)

1. Black Level Calibration:
   • Select "Black Level Calibration" mode
   • Adjust the "Black Level" slider until the rectangle area becomes pure black
2. White Level Calibration:
   • Select "White Level Calibration" mode
   • Adjust the "White Level" slider until the rectangle area becomes pure white

• Enable UI Filter: Excludes UI elements from luminance statistics
• Show Filter Effect: Visualizes filtered pixels (red=too bright, blue=too dark)
• Adjust Filter Thresholds: Modify dark and light filter thresholds based on UI brightness

• Sampling Area: Choose full-screen or custom area sampling
• History Smoothing Algorithm:
  • Off: No history smoothing
  • Preserve (Min/Max): Preserves historical extremes
  • Average (17-frame mean): 17-frame average smoothing
• Debug View: Enables display of all reduction textures and historical data

1. Luminance Calculation: Uses

   max(max(r,g),b)

    formula to calculate pixel luminance
2. Multi-level Reduction: Reduces 1024x1024 sampling to 1x1 statistics through 5 stages of 4x4 reduction
3. History Buffer: Uses 4x4 texture as a 16-frame circular buffer
4. Color Calibration: Maps original image to screen displayable range

1024x1024 → 256x256 → 64x64 → 16x16 → 4x4 → 1x1

• TextureMip0-5: Multi-level reduction textures
• TextureMip4_History: 16-frame history buffer

• Calibration View: Select calibration mode (Off/Black Level Calibration/White Level Calibration)
• Black Level: Black level calibration value
• White Level: White level calibration value

• Enable Auto calibration: Enable/disable automatic calibration
• Min White Limiter: Limits detected maximum raw brightness
• Max Black Limiter: Limits detected raw minimum brightness

• Enable UI Filter: Enable/disable UI filtering
• Show Filter Effect: Display filtered pixels
• UI Filter Black Level: Threshold for filtering overly dark UI pixels
• UI Filter White Level: Threshold for filtering overly light UI pixels

• Show Sampling Border: Display sampling area border
• Sampling Area: Select sampling area (Full Screen/Custom Area)
• Custom Area Center: Center position of custom sampling area
• Custom Area Size: Size of custom sampling area

• History Smoothing Algorithm: Select history smoothing algorithm
• Enable Debug View: Display all reduction textures

• Added brightness extreme smoothing system
• Added UI filtering functionality
• Adjusted UI interface

• Initial version created

• Author: 灰灰蓝
• Email: This email address is being protected from spambots. You need JavaScript enabled to view it.
• WeChat: Rs200215

1. This shader aims to improve game visuals, but results may vary depending on the game and display
2. It's recommended to use calibration mode for manual calibration before enabling auto calibration
3. For HDR content, white level limits may need adjustment
4. If screen flickering occurs, try adjusting the history smoothing algorithm

BlueGary wrote:

This is my first shader.So there may be many shortcomings.
I hope it can help you achieve perfectly restored and calibrated images with accurate details.
The following is the readme.

Source code：

/*
 * MIT License
 * Copyright (C) 2025 灰灰蓝（[email protected]）
 * 本程序是自由软件：你可以随意再分发和/或依照MIT通用公共许可证修改。
 * 如果其作为模块使用在其他软件上，应当标注着色器或功能名为SCAC。
 * 我希望这个着色器可以改善现在的游戏画面，
 * 所以任何人都可以随意提取和修改这个着色器并将其作为模块使用。
 * 发布该程序是希望它能有用，但是并无保障；
 * 甚至连可销售和符合某个特定的目的都不保证。
 * 作者对本软件的使用和分发无任何约束力，故不承担任何相关的法律责任！
 * SCAC
 * 屏幕颜色自动校准
 * Screen Colour Automatic Calibration
 * by 灰灰蓝 [email protected] WeChat Rs200215
 * version 0.08
 * version 0.01 Create at 2025/12/13
 * TODO 添加亮度极值平滑系统。√
 * TODO 添加ui过滤。√
 * TODO 调整ui。√
 * version 0.04 Create at 2025/12/18
 * TODO 改进亮度极值平滑，使其不依赖历史值。√
 * version 0.05 修复了UIFilter不生效的问题。
 * version 0.06 改进了亮度计算的算法。
 * version 0.07 添加了GAMMA调整。
 * version 0.08 删除了历史帧平滑算法，改为单帧平滑算法。
 * version 0.08 Crate at 2025/12/19
 * TODO 改进检测算法，使用单纹理或计算着色器以提高性能。
 */
#include "ReShadeUI.fxh"
uniform int CalibrationMode <
    ui_category = "屏幕校准/Screen calibration";
    ui_text = "屏幕校准图像";
    ui_type = "combo";
    ui_label = "Calibration View";
    ui_tooltip = "选择校准图像/Select the calibration mode.";
    ui_items = "不显示/Off\0黑位校准/Black Level Calibration\0白位校准/White Level Calibration\0";
> = 0;
uniform float ScreenMin <
    ui_category = "屏幕校准/Screen calibration";
    ui_text = "屏幕黑位";
    ui_label = "Black Level";
    ui_tooltip = "选择黑位校准，调整此控件，使画面刚好纯黑/Select black level calibration and adjust this control so that the picture is just pure black.";
    ui_type = "drag";
    ui_min = 0.0;
    ui_max = 1.0;
    ui_step = 0.00001f;
> = 0.0;
uniform float ScreenMax <
    ui_category = "屏幕校准/Screen calibration";
    ui_text = "屏幕白位";
    ui_label = "White Level";
    ui_tooltip = "选择白位校准，调整此控件，使画面刚好纯白/Select white level calibration and adjust this control so that the picture is just pure white.";
    ui_type = "drag";
    ui_min = 0.0;
    ui_max = 50.0;
    ui_step = 0.001f;
> = 1.0;
uniform bool EnableAutoStats <
    ui_category = "自动校正/Auto calibration";
    ui_label = "开启自动校正/Enable Auto calibration";
    ui_tooltip = "将原始画面映射到屏幕范围/Map the original image to the screen range";
> = true;
uniform float WhiteLimiter <
    ui_text = "最小白位限制（为0时无限制/Unlimited for 0）";
    ui_category = "自动校正/Auto calibration";
    ui_type = "slider";
    ui_min = 0.00; ui_max = 1.0;
    ui_step = 0.01f;
    ui_label = "Min White Limiter";
    ui_tooltip = "限制检测到的原始最高亮度，避免阴暗画面过亮/Limit the detected maximum raw brightness to prevent overly bright in dim image";
> = 0.95;
uniform float BlackLimiter <
    ui_text = "最大黑位限制（为1时无限制/Unlimited for 1）";
    ui_category = "自动校正/Auto calibration";
    ui_type = "slider";
    ui_min = 0.00; ui_max = 1.0;
    ui_step = 0.01f;
    ui_label = "Max Black Limiter";
    ui_tooltip = "限制检测到的原始最低亮度，避免将灰色校准成黑色/Limit the detected raw minimum brightness to avoid calibrating grey as black";
> = 0.10;
uniform bool EnableUIFilter <
    ui_category = "UI过滤/UI filter";
    ui_label = "开启UI过滤/Enable UI Filter";
    ui_tooltip = "启用UI滤除功能，排除UI元素对亮度统计的影响/Enable UI filtering to exclude UI elements from luminance statistics.";
> = true;
uniform bool ShowFilterEffect <
    ui_category = "UI过滤/UI filter";
    ui_label = "显示过滤效果/Show Filter Effect";
    ui_tooltip = "显示滤除效果：确保纯红和纯蓝不在游戏画面中出现，只在ui出现/Show filtering effect: ensure pure red and pure blue do not appear in the game screen, only in the UI";
> = true;
uniform float UiFilterBlack <
    ui_text = "ui暗色过滤";
    ui_category = "UI过滤/UI filter";
    ui_type = "slider";
    ui_min = 0.0; ui_max = 0.02;
    ui_step = 0.000001f;
    ui_label = "UI Filter Black Level";
    ui_tooltip = "滤除UI过暗像素的阈值/Threshold for filtering overly dark UI pixels.";
> = 0.0;
uniform float UiFilterWhite <
    ui_text = "ui亮色过滤";
    ui_category = "UI过滤/UI filter";
    ui_type = "drag";
    ui_min = 0.5; ui_max = 100.0;
    ui_step = 0.001f;
    ui_label = "UI Filter White Level";
    ui_tooltip = "滤除UI过亮像素的阈值/Threshold for filtering overly light UI pixels.";
> = 100.0;
uniform float3 RGBGamma <
    ui_text = "明暗调整";
    ui_type = "drag";
    ui_min = 0.0; ui_max = 2.0;
    ui_step = 0.001f;
    ui_label = "Gamma";
    ui_tooltip = "调整画面整体明暗/Adjust the overall brightness and contrast of the image.";
> = 1.0;
uniform bool ShowSamplingBorder <
    ui_category = "采样/Sampling";
    ui_label = "Show Sampling Border";
    ui_tooltip = "显示采样区域的边界/Show sampling area border.";
> = false;
uniform int SamplingAera <
    ui_category = "采样/Sampling";
    ui_type = "combo";
    ui_label = "Sampling Aera";
    ui_tooltip = "选择采样区域/Select sampling aera.";
    ui_items = "Full Screen\0Custom Area\0";
> = 0;
uniform float2 CustomAreaCenter <
    ui_text = "采样区域位置";
    ui_category = "采样/Sampling";
    ui_type = "slider";
    ui_min = 0.0; ui_max = 1.0;
    ui_label = "Custom Area Center";
    ui_tooltip = "自定义采样区域的中心位置/Center position of custom sampling area. 1.0 = default center.";
> = float2(0.5, 0.5);
uniform float2 CustomAreaSize <
    ui_text = "采样区域大小";
    ui_category = "采样/Sampling";
    ui_type = "slider";
    ui_min = 0.0; ui_max = 2.0;
    ui_label = "Custom Area Size";
    ui_tooltip = "自定义采样区域的大小/Size of custom sampling area. 1.0 = default size (1024x1024 pixels).";
> = float2(1.0, 1.0);
uniform int Smoothness <
    ui_category = "Advance";
    ui_type = "slider";
    ui_label = "Smoothness";
    ui_tooltip = "平滑度控制，值越大变化越平滑/Smoothness control, higher values result in smoother changes.";
    ui_min = 1;
    ui_max = 200;
    ui_step = 1;
> = 200;
uniform bool EnableDebug <
    ui_category = "Advance";
    ui_label = "Enable Debug View";
    ui_tooltip = "启用调试视图，显示所有规约纹理/Enable debug view to display all shader textures.";
> = false;
#include "ReShade.fxh"
// ============================================================================
// 辅助函数
// ============================================================================
// 计算像素亮度：min(min(r,g),b) - 单通道简化,min确保黑位准确和画面稳定。
float CalculateLuminance(float3 color)
{
    return min(min(color.r, color.g), color.b);//(color.r + color.g + color.b)/3;
}
// 颜色校准函数 - 支持scRGB/HDR
float3 ColorCalibration(float3 color,
                        float3 minColor,
                        float3 maxColor,
                        float3 useingMinColor,
                        float3 useingMaxColor)
{
    // 应用自动调整限制和ui滤除
    useingMaxColor = max(useingMaxColor, ScreenMax * WhiteLimiter);
    useingMinColor = min(useingMinColor, ScreenMin + BlackLimiter);
    color = clamp(color,UiFilterBlack,UiFilterWhite);
    // 归一化color并应用gamma调整
    color = (color - useingMinColor) / (useingMaxColor - useingMinColor);
    color = clamp(color,0,1);
    color = pow(color, 1.0 / RGBGamma);
    color = color * (useingMaxColor - useingMinColor) + useingMinColor;
    // 校准黑位和白位（合并为一步）
    color = ScreenMin + (color - useingMinColor)* (ScreenMax - ScreenMin)
            / (useingMaxColor - useingMinColor);
    return color;
}
// 绘制校准图案函数
float3 DrawCalibrationPattern(float2 texcoord, int mode)
{
    // 计算4x4网格的单元格大小
    float cellWidth = 1.0 / 4.0;  // 每个单元格占屏幕宽度的1/4
    float cellHeight = 1.0 / 4.0; // 每个单元格占屏幕高度的1/4

    // 矩形占单元格面积的75%，所以矩形大小为单元格大小的sqrt(0.75) ≈ 0.866
    float rectSize = 0.866; // sqrt(0.75)

    // 矩形在单元格内的偏移量，使其居中
    float rectOffset = (1.0 - rectSize) * 0.5;

    // 确定当前像素属于哪个网格单元格
    int cellX = floor(texcoord.x / cellWidth);
    int cellY = floor(texcoord.y / cellHeight);

    // 计算在单元格内的归一化坐标
    float cellLocalX = (texcoord.x - cellX * cellWidth) / cellWidth;
    float cellLocalY = (texcoord.y - cellY * cellHeight) / cellHeight;

    // 检查当前像素是否在矩形区域内
    bool inRect = (cellLocalX >= rectOffset && cellLocalX <= rectOffset + rectSize &&
                   cellLocalY >= rectOffset && cellLocalY <= rectOffset + rectSize);

    // 根据校准模式返回颜色
    if (mode == 1) // 黑位校准
    {
        // 背景：纯黑，矩形：ScreenMin
        return inRect ? ScreenMin : float3(0.0, 0.0, 0.0);
    }
    else if (mode == 2) // 白位校准
    {
        // 背景：1e6（高亮度白色），矩形：ScreenMax
        float3 whiteBackground = float3(1e6, 1e6, 1e6);
        return inRect ? ScreenMax : whiteBackground;
    }

    // 如果不是校准模式，返回黑色（不应该到达这里）
    return float3(0.0, 0.0, 0.0);
}
// 通用4x4归约函数
float4 ReductionPass(float4 position : SV_Position, float2 texcoord : TexCoord, sampler2D inputSampler, float2 pixelSize) : SV_Target
{
    // texcoord是归一化坐标[0,1]
    // 每个输出像素对应输入纹理中的4x4块
    // 计算4x4块的起始坐标（从中心偏移-1.5个像素）将初始采样点从4x4的中心移到左上角第一个像素中心。
    float2 startCoord = texcoord - float2(1.5 * pixelSize.x, 1.5 * pixelSize.y);

    // 采样4x4区域的16个像素
    float minVal = 1e6;     // 初始化为很大的值，支持scRGB/HDR（可能超过1000尼特）
    float maxVal = 0.0;     // 初始化为很小的值

    for (int y = 0; y < 4; y++)     // 这个循环用来遍历4x4块采样。
    {
        for (int x = 0; x < 4; x++)
        {
            float2 sampleCoord = startCoord + float2(x * pixelSize.x, y * pixelSize.y);
            // 确保采样坐标在有效范围内
            // sampleCoord = clamp(sampleCoord, pixelSize * 0.5, 1.0 - pixelSize * 0.5);注释掉因为这个clamp似乎并不必要
            float4 sampleVal = tex2D(inputSampler, sampleCoord);

            minVal = min(minVal, sampleVal.r);
            maxVal = max(maxVal, sampleVal.g);
        }
    }

    // 存储结果：R通道存最小值，G通道存最大值
    return float4(minVal, maxVal, 0.0, 1.0);
}
// ============================================================================
// 纹理定义
// 固定5次归约：1024 -> 256 -> 64 -> 16 -> 4 -> 1
// ============================================================================
// 纹理0：1024x1024 - 存储下采样后的亮度值
texture2D TextureMip0 <
    pooled = true;
>
{
    Width = 1024;
    Height = 1024;
    Format = RGBA16F;
};
sampler2D SamplerMip0 {
    Texture = TextureMip0;
    MinFilter = Point;    // 缩小过滤：点过滤
    MagFilter = Point;    // 放大过滤：点过滤
    MipFilter = Point;    // Mipmap过滤：点过滤
    AddressU = Border;     // U方向寻址：边缘
    AddressV = Border;     // V方向寻址：边缘
};
// 纹理1：256x256 - 第一次4x4归约
texture2D TextureMip1 <
    pooled = true;
>
{
    Width = 256;
    Height = 256;
    Format = RGBA16F;
};
sampler2D SamplerMip1 {
    Texture = TextureMip1;
    MinFilter = Point;    // 缩小过滤：点过滤
    MagFilter = Point;    // 放大过滤：点过滤
    MipFilter = Point;    // Mipmap过滤：点过滤
    AddressU = Border;     // U方向寻址：边缘
    AddressV = Border;     // V方向寻址：边缘
};
// 纹理2：64x64 - 第二次4x4归约
texture2D TextureMip2 <
    pooled = true;
>
{
    Width = 64;
    Height = 64;
    Format = RGBA16F;
};
sampler2D SamplerMip2 {
    Texture = TextureMip2;
    MinFilter = Point;    // 缩小过滤：点过滤
    MagFilter = Point;    // 放大过滤：点过滤
    MipFilter = Point;    // Mipmap过滤：点过滤
    AddressU = Border;     // U方向寻址：边缘
    AddressV = Border;     // V方向寻址：边缘
};
// 纹理3：16x16 - 第三次4x4归约
texture2D TextureMip3 <
    pooled = true;
>
{
    Width = 16;
    Height = 16;
    Format = RGBA16F;
};
sampler2D SamplerMip3 {
    Texture = TextureMip3;
    MinFilter = Point;    // 缩小过滤：点过滤
    MagFilter = Point;    // 放大过滤：点过滤
    MipFilter = Point;    // Mipmap过滤：点过滤
    AddressU = Border;     // U方向寻址：边缘
    AddressV = Border;     // V方向寻址：边缘
};
// 纹理4：4x4 - 第四次4x4归约
texture2D TextureMip4 <
    pooled = true;
>
{
    Width = 4;
    Height = 4;
    Format = RGBA16F;
};
sampler2D SamplerMip4 {
    Texture = TextureMip4;
    MinFilter = Point;    // 缩小过滤：点过滤
    MagFilter = Point;    // 放大过滤：点过滤
    MipFilter = Point;    // Mipmap过滤：点过滤
    AddressU = Border;     // U方向寻址：边缘
    AddressV = Border;     // V方向寻址：边缘
};
// 纹理5：1x1 - 第五次4x4归约（最终结果）
texture2D TextureMip5 <
    pooled = true;
>
{
    Width = 1;
    Height = 1;
    Format = RGBA16F;
};
sampler2D SamplerMip5 {
    Texture = TextureMip5;
    MinFilter = Point;    // 缩小过滤：点过滤
    MagFilter = Point;    // 放大过滤：点过滤
    MipFilter = Point;    // Mipmap过滤：点过滤
    AddressU = Border;     // U方向寻址：边缘
    AddressV = Border;     // V方向寻址：边缘
};
// ============================================================================
// Pass着色器
// ============================================================================
// Pass 1：将后缓冲区采样到1024x1024并计算亮度
float4 pass0_DownsampleTo1024(float4 position : SV_Position, float2 texcoord : TexCoord) : SV_Target
{
    // 测试模式：输出测试图案以验证坐标映射
    // R通道：水平渐变（0到1）
    // G通道：垂直渐变（0到1）
    // B通道：固定0
    // 这样我们可以清楚地看到纹理是否覆盖整个区域

    // float2 testPattern = texcoord; // 直接使用texcoord作为渐变

    // 存储到TextureMip0（R通道存水平渐变，G通道存垂直渐变）
    // return float4(testPattern.x, testPattern.y, 0.0, 1.0);

    // 计算像素大小（用于边界检查）
    float2 pixelSize = 1.0 / float2(BUFFER_WIDTH, BUFFER_HEIGHT);

    // 根据采样模式计算采样坐标
    float2 sampleCoord;
    [branch]
    if (SamplingAera == 0) // 全屏模式
    {
        // 直接使用texcoord作为采样坐标
        sampleCoord = texcoord;
    }
    else // 自定义模式 (SamplingAera == 1)
    {
        // 采样区域
        float2 sampleSize = float2(1024*CustomAreaSize.x*pixelSize.x, 1024*CustomAreaSize.y*pixelSize.y);

        float2 sampleCenter = CustomAreaCenter;

        // 将1024x1024纹理坐标映射到自定义区域
        // 公式：中心 + (texcoord - 0.5) * 大小
        sampleCoord = sampleCenter + (texcoord - 0.5) * sampleSize;
    }

    // 注意：这里不需要clamp，因为AddressU = Border; AddressV = Border;
    // 允许采样坐标超过[0,1]范围，边缘模式会返回边界颜色

    // 从后缓冲区采样RGB值（使用Point过滤直接采样）
    float3 color = tex2D(ReShade::BackBuffer, sampleCoord).rgb;

    // 计算亮度（单通道）
    float luminance = CalculateLuminance(color);
    // UI滤除（如果启用）
    [branch]
    if (EnableUIFilter)
    {
        // 应用滤除
        luminance = clamp(luminance,UiFilterBlack,UiFilterWhite);
        /*
        luminance += (luminance < UiFilterBlack) * UiFilterBlack;
        Luminance -= (Luminance > UiFilterWhite) * UiFilterWhite;
        */
    }

    // 存储到TextureMip0（R通道存亮度，G通道存相同值用于后续处理）
    return float4(luminance, luminance, 0.0, 1.0);
}
// Pass 2：第一次4x4归约（1024x1024 -> 256x256）
float4 Pass2_Reduction1(float4 position : SV_Position, float2 texcoord : TexCoord) : SV_Target
{
    return ReductionPass(position, texcoord, SamplerMip0, 1.0 / 1024.0);
}
// Pass 3：第二次4x4归约（256x256 -> 64x64）
float4 Pass2_Reduction2(float4 position : SV_Position, float2 texcoord : TexCoord) : SV_Target
{
    return ReductionPass(position, texcoord, SamplerMip1, 1.0 / 256.0);
}
// Pass 4：第三次4x4归约（64x64 -> 16x16）
float4 Pass3_Reduction3(float4 position : SV_Position, float2 texcoord : TexCoord) : SV_Target
{
    return ReductionPass(position, texcoord, SamplerMip2, 1.0 / 64.0);
}
// Pass 5：第四次4x4归约（16x16 -> 4x4）
float4 Pass4_Reduction5(float4 position : SV_Position, float2 texcoord : TexCoord) : SV_Target
{
    return ReductionPass(position, texcoord, SamplerMip3, 1.0 / 16.0);
}
// Pass 6：第五次4x4归约（4x4 -> 1x1）和平滑计算
float4 Pass5_Reduction5(float4 position : SV_Position, float2 texcoord : TexCoord) : SV_Target
{
    // 执行正常的4x4归约
    float4 result = ReductionPass(position, texcoord, SamplerMip4, 1.0 / 4.0);

    // 读取上一帧的平滑值（从TextureMip5的B和A通道）
    float4 prevFrame = tex2D(SamplerMip5, float2(0.5, 0.5));
    float prevSmoothMin = prevFrame.b;
    float prevSmoothMax = prevFrame.a;

    // 获取当前帧的最小值和最大值
    float currentMin = result.r;
    float currentMax = result.g;

    // 计算差值（考虑正负）
    float diffMin = currentMin - prevSmoothMin;
    float diffMax = currentMax - prevSmoothMax;

    // 计算平滑步长（1.0 / Smoothness）
    float smoothStep = 0.1 / float(Smoothness);

    // 应用平滑公式：smoothResult = result + min(abs(diff), smoothStep) * sign(diff)
    float smoothMin = prevSmoothMin + min(abs(diffMin), smoothStep) * sign(diffMin);
    float smoothMax = prevSmoothMax + min(abs(diffMax), smoothStep) * sign(diffMax);

    // 写入结果：
    // R通道：当前帧最小值
    // G通道：当前帧最大值
    // B通道：平滑后的最小值
    // A通道：平滑后的最大值
    result.r = currentMin;
    result.g = currentMax;
    result.b = smoothMin;
    result.a = smoothMax;

    return result;
}

// Pass 6：最终颜色校准
float3 Pass6_FinalCalibration(float4 position : SV_Position, float2 texcoord : TexCoord) : SV_Target
{
    // 检查校准模式
    [branch]
    if (CalibrationMode == 1 || CalibrationMode == 2)
    {
        // 显示校准图案
        return DrawCalibrationPattern(texcoord, CalibrationMode);
    }

    // 从后缓冲区采样
    float3 color = tex2D(ReShade::BackBuffer, texcoord).rgb;

    float luminance = CalculateLuminance(color);
    [branch]
    if (ShowFilterEffect)
    {
        // 找到被滤除的像素
        if (luminance < UiFilterBlack)
        {
            color = float3(0,0,1);
        }
        else if (luminance > UiFilterWhite)
        {
            color = float3(1,0,0);
        }
        //color = all(clamp(luminance,UiFilterBlack,UiFilterWhite));
    }
    // 将texcoord转换为像素坐标（用于调试视图）
    uint x = (uint)(texcoord.x * BUFFER_WIDTH);
    uint y = (uint)(texcoord.y * BUFFER_HEIGHT);

    // 获取统计结果
    float minColor = 0.0;
    float useingMinColor = 0.0;
    float maxColor = 1000.0;
    float useingMaxColor = 1000.0;
    // 从最终1x1纹理读取结果
    float4 finalStats = tex2D(SamplerMip5, float2(0.5, 0.5));
    minColor = finalStats.r;
    maxColor = finalStats.g;
    useingMinColor = finalStats.b;
    useingMaxColor = finalStats.a;

    // 防止除零
    maxColor = max(maxColor, minColor + 0.001);
    useingMaxColor = max(useingMaxColor,useingMinColor + 0.1);

    // 调试视图 - 显示规约纹理
    [branch]
    if (EnableDebug)
    {
        // 右侧显示区域：显示6个规约纹理，每个占屏幕高度的1/6
        float rightDisplaySize = BUFFER_HEIGHT / 6.0;
        float rightDisplayWidth = rightDisplaySize;
        float rightDisplayHeight = rightDisplaySize;

        // 检查当前像素是否在屏幕右侧的显示区域内
        if (x > BUFFER_WIDTH - rightDisplayWidth)
        {
            // 计算在显示区域内的相对位置
            uint displayX = x - (BUFFER_WIDTH - (uint)rightDisplayWidth);
            uint displayY = y;

            // 计算当前像素属于哪个纹理（0-5）
            uint textureIndex = displayY / (uint)rightDisplayHeight;

            // 确保纹理索引在0-5范围内
            if (textureIndex < 6)
            {
                // 计算在当前纹理显示区域内的相对位置（归一化到[0,1]）
                float localY = (displayY % (uint)rightDisplayHeight) / rightDisplayHeight;
                float localX = displayX / rightDisplayWidth;

                // 根据纹理索引采样对应的纹理
                float4 mipValue;
                if (textureIndex == 0)
                {
                    // TextureMip0: 1024x1024
                    float2 mipCoord = float2(localX, localY);
                    mipValue = tex2D(SamplerMip0, mipCoord);
                }
                else if (textureIndex == 1)
                {
                    // TextureMip1: 256x256
                    float2 mipCoord = float2(localX, localY);
                    mipValue = tex2D(SamplerMip1, mipCoord);
                }
                else if (textureIndex == 2)
                {
                    // TextureMip2: 64x64
                    float2 mipCoord = float2(localX, localY);
                    mipValue = tex2D(SamplerMip2, mipCoord);
                }
                else if (textureIndex == 3)
                {
                    // TextureMip3: 16x16
                    float2 mipCoord = float2(localX, localY);
                    mipValue = tex2D(SamplerMip3, mipCoord);
                }
                else if (textureIndex == 4)
                {
                    // TextureMip4: 4x4
                    float2 mipCoord = float2(localX, localY);
                    mipValue = tex2D(SamplerMip4, mipCoord);
                }
                else // textureIndex == 5
                {
                    // TextureMip5: 1x1 - 总是采样中心点
                    mipValue = tex2D(SamplerMip5, float2(0.5, 0.5));
                }

                // R通道显示为红色，G通道显示为绿色（保持一致的显示风格）
                return float3(mipValue.r, mipValue.g, 0.0);
            }
        }

    }

    // 显示采样边界（如果启用）
    [branch]
    if (ShowSamplingBorder)
    {
        // 紫色边界颜色
        const float3 BORDER_COLOR = float3(1.0, 0.0, 1.0); // 紫色

        // 边界宽度（3像素）
        const float BORDER_WIDTH = 3.0;

        // 计算归一化的边界宽度
        float borderWidthX = BORDER_WIDTH / BUFFER_WIDTH;
        float borderWidthY = BORDER_WIDTH / BUFFER_HEIGHT;

        // 计算当前像素的归一化坐标
        float2 normalizedCoord = float2(x / float(BUFFER_WIDTH), y / float(BUFFER_HEIGHT));

        // 根据采样模式确定边界区域
        float2 borderMin, borderMax;

        if (SamplingAera == 0) // 全屏模式
        {
            // 整个屏幕的边界
            borderMin = float2(0.0, 0.0);
            borderMax = float2(1.0, 1.0);
        }
        else // 自定义模式
        {
            // 计算像素大小（与pass0_DownsampleTo1024一致）
            float2 pixelSize = 1.0 / float2(BUFFER_WIDTH, BUFFER_HEIGHT);

            // 采样区域大小（与pass0_DownsampleTo1024一致）
            float2 sampleSize = float2(1024*CustomAreaSize.x*pixelSize.x, 1024*CustomAreaSize.y*pixelSize.y);
            float2 sampleCenter = CustomAreaCenter;

            // 计算采样区域的边界
            float2 halfSize = sampleSize * 0.5;
            borderMin = sampleCenter - halfSize;
            borderMax = sampleCenter + halfSize;

            // 注意：这里不需要clamp，因为边界可以超过[0,1]范围
            // 边缘模式允许采样坐标超过[0,1]范围
        }

        // 检查当前像素是否在边界区域内（3像素宽）
        bool isInBorder = false;

        // 检查左边界
        if (normalizedCoord.x >= borderMin.x && normalizedCoord.x <= borderMin.x + borderWidthX &&
            normalizedCoord.y >= borderMin.y && normalizedCoord.y <= borderMax.y)
        {
            isInBorder = true;
        }
        // 检查右边界
        else if (normalizedCoord.x >= borderMax.x - borderWidthX && normalizedCoord.x <= borderMax.x &&
                normalizedCoord.y >= borderMin.y && normalizedCoord.y <= borderMax.y)
        {
            isInBorder = true;
        }
        // 检查上边界
        else if (normalizedCoord.y >= borderMin.y && normalizedCoord.y <= borderMin.y + borderWidthY &&
                normalizedCoord.x >= borderMin.x && normalizedCoord.x <= borderMax.x)
        {
            isInBorder = true;
        }
        // 检查下边界
        else if (normalizedCoord.y >= borderMax.y - borderWidthY && normalizedCoord.y <= borderMax.y &&
                normalizedCoord.x >= borderMin.x && normalizedCoord.x <= borderMax.x)
        {
            isInBorder = true;
        }

        // 如果在边界内，返回紫色
        if (isInBorder)
        {
            return BORDER_COLOR;
        }
    }
    if (EnableAutoStats)
    {
        // 应用颜色校准
        minColor = float3(minColor, minColor, minColor);
        maxColor = float3(maxColor, maxColor, maxColor);
        useingMinColor = float3(useingMinColor, useingMinColor, useingMinColor);
        useingMaxColor = float3(useingMaxColor, useingMaxColor, useingMaxColor);
        color = ColorCalibration(color, minColor, maxColor,useingMinColor,useingMaxColor);
    }
    return color;
}
// ============================================================================
// 技术定义
// ============================================================================
technique SCAC
{
    pass Pass0_Downsample
    {
        VertexShader = PostProcessVS;
        PixelShader = pass0_DownsampleTo1024;
        RenderTarget = TextureMip0;
    }

    pass Pass1_Reduction1
    {
        VertexShader = PostProcessVS;
        PixelShader = Pass2_Reduction1;
        RenderTarget = TextureMip1;
    }

    pass Pass2_Reduction2
    {
        VertexShader = PostProcessVS;
        PixelShader = Pass2_Reduction2;
        RenderTarget = TextureMip2;
    }

    pass Pass3_Reduction3
    {
        VertexShader = PostProcessVS;
        PixelShader = Pass3_Reduction3;
        RenderTarget = TextureMip3;
    }

    pass Pass4_Reduction4
    {
        VertexShader = PostProcessVS;
        PixelShader = Pass4_Reduction5;
        RenderTarget = TextureMip4;
    }

    pass Pass5_Reduction5
    {
        VertexShader = PostProcessVS;
        PixelShader = Pass5_Reduction5;
        RenderTarget = TextureMip5;
    }

    pass Pass6_Final
    {
        VertexShader = PostProcessVS;
        PixelShader = Pass6_FinalCalibration;
    }
}

SCAC (Screen Colour Automatic Calibration) is a ReShade shader for automatic screen color calibration, optimizing game display quality.FeaturesCore Features

• Automatic Color Calibration: Real-time screen analysis with automatic black and white level adjustment
• Screen Calibration Tools: Provides black and white level calibration patterns for manual calibration
• UI Filtering: Intelligently excludes UI elements from luminance statistics
• Single-frame Smoothing: Uses smoothing algorithm to avoid sudden brightness changes, providing stable color calibration

Advanced Features

• Custom Sampling Area: Supports full-screen or custom area sampling
• HDR/scRGB Support: Compatible with high dynamic range displays
• Debug View: Visualizes all reduction textures and historical data
• Real-time Statistics: Displays current frame's minimum/maximum luminance values

Installation

1. Ensure  ReShade  is installed
2. Copy the

   SCAC.fx

    file to ReShade's Shaders directory
3. Enable ReShade in-game and add the SCAC effect

UsageBasic Settings

1. Enable Auto Calibration: Turn on "Enable Auto calibration" in the "Auto calibration" category
2. Adjust Limiters:
   • Min White Limiter: Prevents overly bright dim scenes (recommended: 0.95)
   • Max Black Limiter: Avoids calibrating grey as black (recommended: 0.10)

Screen Calibration

1. Black Level Calibration:
   • Select "Black Level Calibration" mode
   • Adjust the "Black Level" slider until the rectangle area becomes pure black
2. White Level Calibration:
   • Select "White Level Calibration" mode
   • Adjust the "White Level" slider until the rectangle area becomes pure white

UI Filtering

• Enable UI Filter: Excludes UI elements from luminance statistics
• Show Filter Effect: Visualizes filtered pixels (red=too bright, blue=too dark)
• Adjust Filter Thresholds: Modify dark and light filter thresholds based on UI brightness

Advanced Settings

• Sampling Area: Choose full-screen or custom area sampling
• Smoothness Control: Adjust smoothness parameter, higher values result in smoother changes
• Debug View: Enables display of all reduction textures and historical data

Technical DetailsHow It Works

1. Luminance Calculation: Uses

   min(min(r,g),b)

    formula to calculate pixel luminance
2. Multi-level Reduction: Reduces 1024x1024 sampling to 1x1 statistics through 5 stages of 4x4 reduction
3. Single-frame Smoothing: Uses smoothing algorithm to avoid sudden brightness changes, providing stable color calibration
4. Color Calibration: Maps original image to screen displayable range

Reduction Pipeline

1024x1024 → 256x256 → 64x64 → 16x16 → 4x4 → 1x1

Texture Usage

• TextureMip0-4: Multi-level reduction textures (1024x1024 → 4x4)
• TextureMip5: Final statistics texture (1x1), stores current frame brightness extremes and smoothed historical values

Parameter DescriptionScreen Calibration

• Calibration View: Select calibration mode (Off/Black Level Calibration/White Level Calibration)
• Black Level: Black level calibration value
• White Level: White level calibration value

Auto Calibration

• Enable Auto calibration: Enable/disable automatic calibration
• Min White Limiter: Limits detected maximum raw brightness
• Max Black Limiter: Limits detected raw minimum brightness

UI Filtering

• Enable UI Filter: Enable/disable UI filtering
• Show Filter Effect: Display filtered pixels
• UI Filter Black Level: Threshold for filtering overly dark UI pixels
• UI Filter White Level: Threshold for filtering overly light UI pixels

Sampling

• Show Sampling Border: Display sampling area border
• Sampling Area: Select sampling area (Full Screen/Custom Area)
• Custom Area Center: Center position of custom sampling area
• Custom Area Size: Size of custom sampling area

Advanced Settings

• Smoothness Control: Adjust smoothness parameter, higher values result in smoother changes
• Enable Debug View: Display all reduction textures

Version Historyv0.08 (2025/12/19)

• Removed historical frame smoothing algorithm, changed to single-frame smoothing algorithm
• Added GAMMA adjustment function
• Improved smoothness control parameters

v0.07 (2025/12/19)

• Added GAMMA adjustment function

v0.06 (2025/12/18)

• Fix the issue where UI filter did not work correctly
• Change the brightness calculation algorithm to min(r,g,b)

v0.05 (2025/12/18)

• Fixed the issue where UIFilter did not work

v0.04 (2025/12/18)

• Added brightness extreme smoothing system
• Added UI filtering functionality
• Adjusted UI interface

v0.01 (2025/12/13)

• Initial version created

LicenseMIT License Copyright (C) 2025 灰灰蓝（This email address is being protected from spambots. You need JavaScript enabled to view it.）Contact

• Author: 灰灰蓝
• Email: This email address is being protected from spambots. You need JavaScript enabled to view it.
• WeChat: Rs200215

Notes

1. This shader aims to improve game visuals, but results may vary depending on the game and display
2. It's recommended to use calibration mode for manual calibration before enabling auto calibration
3. For HDR content, white level limits may need adjustment
4. If screen flickering occurs, try adjusting the smoothness parameter

ContributingIssues and improvement suggestions are welcome. Please ensure compliance with MIT license terms.
